Phase II EVR Components - A4119EVR-020RC Coaxial Reconnectable SafeBreak® Valve
The A4119EVR Coaxial Reconnectable SafeBreak® Valve is a shear pin style reconnectable component designed for use with Balance Phase II Vapor Recovery Systems. A dual poppet design seals off both the fuel and vapor paths upon separation due to customer related “drive-off” occurrences, eliminating fuel spillage, vapor emissions and minimizing damage to the dispenser unit. Complies with the California Air Resources Board CARB Enhanced Vapor Recovery Program EVR Certification Procedures CP-201.
Material
- Body: Aluminum
- O-rings: Buna-N
- Protective Cover: Santoprene
Approvals
- VR-203-Z
- VR-204-Z
- VR-207
- VR-208
- VR-501 (pending)
Installation Instructions
Repair Kits & Service Tools
Visit the Repair Kits & Service Tools page for Installation Instructions:
A4119EVR-020RC Repair Kit
| wdt_ID | Kit No. | Description |
|---|---|---|
| 1 | 49478EVR | Fuel Path O-ring Kit |
| 2 | 495820 | Shear Pin Kit |
| 3 | 495843 | Snap Cover Kit |
| 4 | 495866 | Scuff Guard Kit |
| 5 | 572909 | Clamp Tool |
| 6 | 495989 | Clamp Tool Plate Kit |
